Stylo Laser
1 / 5
18 Months Guarantee & Lifetime Support
Professional efficiency with exceptional after-sales service.
High electrical/optical conversion rate with advanced water cooling system.
Raycus laser source ensures high beam output quality and extreme reliability.
3-12 times faster than YAG types; 2-3 times faster than CO2 laser cutting machines.
Core parts reach up to 100,000 working hours with stable performance.
Smooth cutting surfaces with minimal deformation and professional leveling appearance.
Energy-saving technology consuming only 20%-30% electricity of conventional machines.
| Laser type | Raycus Fiber laser generator |
| Working area | 370*600mm / 600*600mm |
| Laser power | 500W / 800W / 1000W |
| Cutting thickness | ≤6mm (stainless steel) |
| Cutting speed | ≤25m/min |
| Location accuracy | ±0.03mm/m |
| Repeat location accuracy | ±0.02mm/m |
| Equipment power | 20KW |
| Cooling mode | Water cooling |
| Laser wavelength | 1064nm |
| Power supply | 3-phase 380V / 50Hz / 20KVA |
| Machine weight | ≤8000kg |
| Machine dimension | 4300*2500*1600mm |
Suitable Materials:
Industry Applications: Widely used in Advertising Signs, Metal Letters, Kitchenware, Sheet Metal Processing, Elevator Panels, Auto Parts, and Electronic Components.
