Closed Loop DC Motor Control System with Feedback

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Information

Model NO.

60SC40

Number of Stator

Two-Phase

Excitation Mode

HB-Hybrid

Function

Control, Driving

Number of Poles

Operate Mode

Driving

Type

Magnetic-Electric

Certification

ISO9001, Ce, RoHS

Name

Closed Loop DC Motor Control System with Feedback

Transport Package

Green Export Package

Specification

NEMA

Origin

China

HS Code

8501310000

Production Capacity

1,000,000 PCS/Year

Product Overview

Closed Loop DC Motor Control System With Feedback

Technical Parameter

Item	Specifications
Step Angle Accuracy	±5% (full step, no load)
Temperature Rise	50 degree Max
Ambient Temperature	-20 degree to +50 degree
Insulation Resistance	100MΩ Min. 500VDC
Withstand Voltage	500VAC for one minute
Shaft Radial Play	0.02Max. (450g-load)
Shaft Axial Play	0.08Max. (450g-load)

Model Specifications

Model No.	Phase	Step Angle (°)	Holding Torque (Nm)	Rated Current (A)	Resistance (Ω)	Length (mm)	Weight (kg)
60SC30	2	1.8	3	6	0.6	103	1.4
60SC40	2	1.8	4	5.6	0.5	109	1.6

Note: All parameters above are standard. We can customize according to your request (current, voltage, holding torque, body length, etc.) and provide matched stepper motor drivers.

Applications

Our products are widely utilized across various automated industries, including:

3D Printers & Injection Machinery
CNC Routers & Engraving Machines
Stage Lighting Control & Security Surveillance
Medical & Analytical Instruments
Robotic Systems & Office Automation
Textile & Embroidery Equipment

Service & Packaging

Packaging & Shipping

Standard export carton with shipping marks
Waterproof packing with shock-absorbing EPE
Customized packaging per client requirements

Professional Service

18 Months Warranty & Life-long maintenance
Lead time: 2-5 days for samples
Support for full product customization
Rapid response to technical inquiries

Frequently Asked Questions

Q1: How to choose the suitable stepper motor?

A1: Key factors include the physical size, length, holding torque, voltage, and current. Once these parameters are confirmed, we can recommend the most suitable model for your application.

Q2: Can you help identify a motor if I have an existing model?

A2: Yes, you can send us the model number or specifications of the motor you are currently using, and we will help you find a matching or improved replacement.

Q3: How is the quality of industrial parts guaranteed?

A3: We use an integrated quality control system including IQC (Incoming), IPQCS (In-process), FQC (Final), and OQC (Out-going) to monitor every stage of production.

Q4: What are the primary advantages of your products?

A4: Our products feature competitive pricing, fast delivery, and high precision. Each unit undergoes strict tolerance checks and is inspected more than three times before shipping.

Q5: What is the standard warranty period?

A5: We provide an 18-month warranty period and offer life-long maintenance services for all our products.

Q6: What is the typical lead time for orders?

A6: For sample orders, the lead time is typically 2 to 5 days. For mass production, the timeline depends on the specific quantities required.
